Synthetic air filters are designed to capture and remove particulate matter, dust, and other pollutants from the air, but they use synthetic materials (such as polyester, polypropylene, or other man-made fibers) instead of traditional materials like cotton or fiberglass. These filters are commonly used in HVAC systems, air purifiers, automotive applications, and industrial environments due to their efficiency, durability, and resistance to moisture.
Description
Product Advantages
- Higher Efficiency: Synthetic materials often offer a higher filtration efficiency, particularly for fine particulate matter.
- Durability: They are generally more durable and resistant to wear and tear compared to natural fibers.
- Moisture Resistance: Synthetic fibers resist moisture absorption, which helps prevent mold growth, unlike natural fiber filters.
- Lightweight: Synthetic filters tend to be lighter, making them easier to handle and install.
- Cost-Effective: They can be more affordable compared to high-end natural fiber options.
Features
| Type | flat mesh panel |
| Frame | galvanized steel, aluminium and stainless steel |
| Filter media | synthetic fiber |
| Grids | aluminium mesh and stainless steel mesh |
| EN 779 Class | G2－G4 |
| Average arrestance | 74%－94%（ASHRAE 52.1-1992） |
| MERV | MERV 3－8（ASHRAE 52.2-1999） |
| DIN 53438 Flammability | F1 |
| UL 900 Standard | CLASS 2 |
| Final pressure drop | (recommender) 150Pa -（maximum）250Pa |
| Max. air flow rate | 125% of nominal air flow rate |
| Max. operating temperature | 100℃ |
| Max. relative humidity | 100% |
| Applications | coarse particle filtration |
Specification
|
Type |
Class |
Arrestance |
Dimensions |
Filtering surface (m2) |
Rate air flow (m3/h) |
Initial pressure drop (Pa) |
||
|
Length (mm) |
Height (mm) |
Thickness (mm) |
||||||
|
PB-70 |
G2 |
70-76% |
592 |
592 |
20-25 |
0.36 |
1800 |
25 |
|
PB-70 |
G2 |
70-76% |
290 |
592 |
20-25 |
0.18 |
1800 |
25 |
|
PB-80 |
G3 |
80-86% |
592 |
592 |
20-25 |
0.36 |
1800 |
30 |
|
PB-80 |
G3 |
80-86% |
290 |
592 |
20-25 |
0.18 |
1800 |
30 |
|
PB-90 |
G4 |
90-94% |
592 |
592 |
20-25 |
0.36 |
1800 |
40 |
|
PB-90 |
G4 |
90-94% |
290 |
592 |
20-25 |
0.18 |
1800 |
40 |
